Plan Review Touch-Screen Table

Plan Review Touch

Height & Tilt Adjust

55" 65" Screen Size

Visually impressive and highly functional the Volanti "Lift & Tilt" touch screen plan review table features an Ultra-HD (4k) 55" or 65" display. The ability to set the display height and angle provides both an ergonomic workspace as well as providing flexibility for single or group use as well as presentations.

It is compatible with all PC applications - some popular software applications we see being used include plan review products such as Bluebeam, Procore, Plangrid, ArcGIS, planning & collaboration software such as Trello and eplan table viewer applications as well as digital whiteboard and presentation applications. For orders or questions: Contact us by form or phone or chat.

FREE: Solid-state Windows 10 workstation (value $1,999) with the purchase of a 65" Plan Review Touch Screen table at normal list price. Cannot be combined with other offers.



touch table

Table

touch table

Collaboration

touch table

Presentation

touch table

Transport

Large Ultra-HD Multi-Touch Monitor

Large Ultra-HD Multi-Touch Monitor

Multi-touch

Pinch, Zoom, Pan

Flat Edge-to-Edge

Easy to clean

High Resolution 4K

Ultra-HD sharp images

Finger, Stylus, Glove

All Supported

Brighter Display

Direct LED Backlit

Responsive

Low Latency

Multiple inputs

HDMI, DisplayPort

Toughened Glass

Aluminum housing

55" & 65"

Screen Size Options






These are the same Volanti touch screen monitors as here: 55" & 65" touch monitors.



touch table

Flat - No Bezel

touch table

Move Handles

touch table

4" Castors

touch table

Cable Management

The Cart: Solid, Adjustable & Mobile

Intuitive Functionality

Stylish, ergonomic and very functional, the details are all there, conveniently located handles, a wired remote control for height and angle adjustment, cable management, locking wheels, accessories to add functionality and convenience. Together with the touch screen monitor it is a versatile electric plan table and presentation display system.

Electric

Tilt & Height

Tilt

Flat to Vertical: 22 sec

Height

Top to Bottom: 29 sec

Mobile

4" wheels

Transportable

Road Case (option)

Accessories

Many



Accessory Options

Options

The Volanti Lift & Tilt touch-screen table has a number of cart related optional accessories including...

As shown on the Right:

• Red: Keyboard storage shelf
• Green: Equipment cover
• Blue: Power cable reel

touch table

Other accessories:

• Power distribution
• 3U rack bracket
• Small shelf
• IR remote control


keyboard storage cable reel pdu rack shelf remote


Workstation Option

Workstation Options

The Volanti Lift & Tilt touch-screen table can be used with your PC, laptop, Microsoft Surface Pro or supplied with the powerful CAD certified HP Z2 Mini G3 Workstation.

Configuration options:

• Intel i3-6100 to i7-7700
• NVidia Quadro M620 option
• HDD or SSD storage
• ISV CAD certified

pc



• Up to 32GB DDR4 RAM
• Windows 10 (other available)
• Wi-Fi, Bluetooth
• Energy Star Qualified Config



Applications

Applications

The Volanti Lift & Tilt touch screen table is a versatile and ergonomic solution for a wide range of personal and team collaboration applications such as plan review, design, training, digital whiteboard, presentation and other commercial applications.

Design & CAD

Plan Review

Presentations

Kanban

Training

Construction






As an electric plan table, or eplan table, we see Bluebeam Revu, Procore, Plangrid as popular applications. For CAD and 3D viewing apps from Adobe, Autodesk Revit and similar are all compatible. For digital whiteboard the Microsoft Digital Whiteboard app works well.

Downloads

Downloads
Brochure: Plan Review Lift & Tilt Touch Table, 55" & 65"

Specifications

Specifications

Design and final assembly in California, USA for commercial use. For orders or questions: Contact us.

TOUCH
55" 4K
65" 4K
Design Edge-to-edge flush design - no raised bezel Edge-to-edge flush design - no raised bezel
Multiple Touches 10 point 10 point
Accuracy <1.5mm accuracy <2mm accuracy
Touch Finger, gloves, stylus Finger, gloves, stylus
Compatibility Windows 7/8/10, Linux, Android versions with native support for USB HID multi-touch. No drivers needed. Windows 7/8/10, Linux, Android versions with native support for USB HID multi-touch. No drivers needed.
DISPLAY
55" 4K
65" 4K
LCD Display 55" LCD with LED backlight 65" LCD with LED backlight
Resolution 3840 x 2160, 4K 3840 x 2160, 4K
Brightness 450 nits 450 nits
Contrast Ratio 4000:1 4000:1
Colors 1.07 Billion 1.07 Billion
Viewing Angle 178° Horizontal & Vertical 178° Horizontal & Vertical
Dimensions 51.4"W x 30.6"H 60.0"W x 35.4"H
INPUTS
55" 4K
65" 4K
HDMI 1 x HDMI 2.0 - 4K @ 60hz
2 x HDMI 1.4 - 1080p @ 60hz		 1 x HDMI 2.0 - 4K @ 60hz
2 x HDMI 1.4 - 1080p @ 60hz
Display Port 1 x DisplayPort 1.2 - 4K @ 60Hz 1 x DisplayPort 1.2 - 4K @ 60Hz
DVI Supports 1080p @ 60hz Supports 1080p @ 60hz
VGA 1 x DB15 1920x1080 @ 60hz 1 x DB15 1920x1080 @ 60hz
SETTINGS
55" 4K
65" 4K
Display:
Buttons & IR
Ethernet, RS-232		 Brightness, contrast, sharpness, color, temperature, backlight brightness, PiP/PbP Brightness, contrast, sharpness, color, temperature, backlight brightness, PiP/PbP
Base:
Buttons &
IR (Option)		 Up/Down, Vertical/Horizontal Up/Down, Vertical/Horizontal
BASE
55" 4K
65" 4K
Travel:
Top/Bottom		 34" - 59" center 34" - 59" center
Timings:
Top/Bottom		 29 seconds 29 seconds
Timings:
Vertical/Horizontal		 22 seconds 22 seconds
Accessories 3U rack, 30ft power reel, equipment cover, keyboard storage shelf, small shelf, power distribution, road case 3U rack, 30ft power reel, equipment cover, keyboard storage shelf, small shelf, power distribution, road case
OTHER
55" 4K
65" 4K
Glass Impact Resistance Ball drop UL60950 (500g/1.3m) Ball drop UL60950 (500g/1.3m)
Cover Glass 3.2mm, Temperature strengthened 3.2mm, Chemically strengthened
Touch Glass Integration Air-gap bonding Air-gap bonding
Touch Glass Sealant Silicon Silicon
Power: Display External type power supply - 100-240VAC, 50/60hz External type power supply - 100-240VAC, 50/60hz
Power: Base External type power supply - 100-240VAC, 50/60hz External type power supply - 100-240VAC, 50/60hz
Operating Conditions 0 to +50°C 0 to +50°C
Weight: Display/Base/Total 65lbs/145lbs/210lbs 105lbs/145lbs/250lbs
Shipping Weight: Display/Base/Total 85lbs/175lbs/260lbs 125lbs/175lbs/300lbs
Approvals FCC class B, CE, UL 60065 FCC class B, CE, UL 60065
PART NUMBERS
55" 4K
65" 4K
Plan Review Lift & Tilt touch-screen VD-554K-T-T VD-654K-T-T
ACCESSORY OPTIONS
3U rack bracket VT-0015-0002
Power cable reel VT-0015-0003
Equipment cover VT-0015-0004
Keyboard storage shelf VT-0015-0005
Small shelf VT-0015-0006
Power distribution VT-0015-0007
